One of the most magical feelings in the military is that moment you finally get back to the tent or barracks and can finally shed your Kevlar helmet and IOTV. That moment, when you can finally breathe and realize just how sweaty you were, is just plain glorious.
As much of a slight pain in the ass (figuratively speaking, of course. Literally, it’s a pain in the lower back and knees) as today’s armor is, it’s come a long way. Take, for instance, the first effective ballistic armor developed by the United States Army for WWI.
I present you to the unsightly behemoth known as the “Brewster Body Shield.”
When America made its entry into the first World War, it was an eye opener. War had changed drastically in only a few short years. Now, cavalry on horseback were useless against a machine gun nest, poison gas was filling the trenches, and fixed-wing, motor-driven airplanes were being used for war just twelve years after the Wright Brothers made their historic flight at Kitty Hawk.
The Italians had started fielding their own updated version of knights’ armor for use by the Arditi, but it had more of a symbolic meaning than any practical use. The Germans began giving their sappers protective armor that could take a few bullets along with protecting its wearer’s vital organs from the shock of explosives. America thought they could outdo them all with their own, suped-up version.
America wanted some sort of protection for its infantrymen if they ever dared to cross the barrage of bullets that flew across No-Man’s Land and they needed it as fast as they could. The U.S. Government turned to a man who created armor intended for boxing training, Dr. Guy Otis Brewster.
Dr. Brewster began creating a suit of armor that was made out of 0.21 inch chrome nickle steel — enough to withstand .303 British bullets at 2,700 ft/s (820 m/s). It was also given a V-shaped design to minimize the direct impact of any oncoming bullets. The whole thing came in two pieces and weighed a total of 110 lbs.
Then came time for the field test. Dr. Brewster invited Army officers and representatives from the steel mills and rubber companies to come witness. Being the insane scientist that he was, he donned the armor himself and stood in the firing line for the test.
His assistant swung at him with a hammer and a sledgehammer before eventually moving on to being shot by a Springfield rifle. He said that being shot it the suit was “only about one-tenth the shock as being struck by a sledgehammer.”
You can watch the recording below.
Despite its protective capabilities, it was deemed too heavy, too clumsy, and way too large to ever be fielded. Dr. Brewster didn’t take that news lightly and wanted to prove its worth. He tested it again and was reportedly able to withstand a hail of bullets from a Lewis Machine Gun — with him inside the suit, obviously.
In the end, he never managed to get the Body Shield approved by the U.S. government — seeing as it was impossibly immobile and occluded visibility almost entirely. He would, however, later make a steel-scaled waistcoat that resembles more modern flak vests.
The Navy has now issued at least one-fourth of the design work and begun further advancing work on systems such as a stealthy “electric drive” propulsion system for the emerging nuclear-armed Columbia-Class ballistic missile submarines by 2021.
“Of the required design disclosures (drawings), 26-percent have been issued, and the program is on a path to have 83-percent issued by construction start,” Bill Couch, spokesman for Naval Sea Systems Command, told Warrior Maven.
The Columbia class is to be equipped with an electric-drive propulsion train, as opposed to the mechanical-drive propulsion train used on other Navy submarines.
In today’s Ohio-class submarines, a reactor plant generates heat which creates steam, Navy officials explained. The steam then turns turbines which produce electricity and also propel the ship forward through “reduction gears” which are able to translate the high-speed energy from a turbine into the shaft RPMs needed to move a boat propeller.
“The electric-drive system is expected to be quieter (i.e., stealthier) than a mechanical-drive system,” a Congressional Research Service report on Columbia-Class submarines from earlier this year states.
Designed to be 560-feet– long and house 16 Trident II D5 missiles fired from 44-foot-long missile tubes, Columbia-Class submarines will use a quieting X-shaped stern configuration.
The “X”-shaped stern will restore maneuverability to submarines; as submarine designs progressed from using a propeller to using a propulsor to improve quieting, submarines lost some surface maneuverability, Navy officials explained.
Navy developers explain that electric-drive propulsion technology still relies on a nuclear reactor to generate heat and create steam to power turbines. However, the electricity produced is transferred to an electric motor rather than so-called reduction gears to spin the boat’s propellers.
The use of an electric motor brings other advantages as well, according to an MIT essay written years ago when electric drive was being evaluated for submarine propulsion.
Using an electric motor optimizes use of installed reactor power in a more efficient way compared with mechanical drive submarines, making more on-board power available for other uses, according to an essay called “Evaluation and Comparison of Electric Propulsion Motors for Submarines,” author Joel Harbour says that on mechanical drive submarine, 80-percent of the total reactor power is used exclusively for propulsion.
“With an electric drive submarine, the installed reactor power of the submarine is first converted into electrical power and then delivered to an electric propulsion motor. The now available electrical potential not being used for propulsion could easily be tapped into for other uses,” he writes.
Research, science and technology work and initial missile tube construction has been underway for several years. One key exercise, called tube-and-hull forging, involves building four-packs of missile tubes to assess welding and construction methods. These structures are intended to load into the boat’s modules as construction advances.
“Early procurement of missile tubes and prototyping of the first assembly of four missile tubes are supporting the proving out of production planning,” Couch said.
While the Columbia-Class is intended to replace the existing fleet of Ohio-Class ballistic missile submarines, the new boats include a number of not-yet-seen technologies as well as different configurations when compared with the Ohio-Class. The Columbia-Class will have 16 launch tubes rather than the 20 tubes current on Ohio boats, yet the Columbias will also be about 2-tons larger, according to Navy information.
The Columbia-Class, to be operational by the 2028, is a new generation of technically advanced submarines intended to quietly patrol the undersea realm around the world to ensure second-strike ability should the US be hit with a catastrophic nuclear attack.
Formal production is scheduled for 2021 as a key step toward fielding of a new generation of nuclear-armed submarines to serve all the way into and beyond the 2080s.The Columbia-Class, to be operational by the 2028, is a new generation of technically advanced submarines intended to quietly patrol the undersea realm around the world to ensure second-strike ability should the US be hit with a catastrophic nuclear attack.
General Dynamics Electric Boat has begun acquiring long-lead items in anticipation of beginning construction; the process involves acquiring metals, electronics, sonar arrays and other key components necessary to build the submarines.
Both the Pentagon and the Navy are approaching this program with a sense of urgency, given the escalation of the current global threat environment. Many senior DoD officials have called the Columbia-Class program as a number one priority across all the services.
“The Columbia-Class submarine program is leveraging enhanced acquisition authorities provided by Congress such as advanced procurement, advanced construction and multi-year continuous production of missile tubes,” Couch added.
