Gigantic warships equipped with massive amounts of firepower, like Arleigh Burke-class destroyers and Nimitz-class carriers, immediately spring to mind when we think “United States Navy.” But not every ship in service is a seafaring behemoth — in fact, cyclone vessels are quite small.
The smallest warships in U.S. Navy service are Cyclone-class patrol craft. The Navy acquired 14 of these ships for special operations work in the 1990s. These small vessels weigh roughly 288 tons, have a crew of 28 personnel, and can hold either nine SEALs or a six-man Coast Guard law-enforcement detachment.
Two Cyclones operate in a joint Navy-Coast Guard exercise.
(U.S. Navy photo by Mass Communication Specialist 2nd Class Sean Furey)
These ships are roughly 178 feet long and have a top speed of 35 knots. They also pack a punch. Cyclones are equipped with two 25mm Bushmaster chain guns and a mix of M2 .50-caliber machine guns, 7.62mm machine guns, and Mk 19 automatic grenade launchers. The ships also can carry the FIM-92 Stinger for air defense.
In some cases, even these tiny ships are too big for special operations work. So for those select missions, Cyclones carry rigid-hull inflatable craft and two combat rubber raiding craft, operated with either a hydraulic lift or a stern ramp. To date, these ships have seen a good amount of action in the Persian Gulf and in the Caribbean.
USS Zephyr (PC 8) catches up to a drug-smuggling go-fast. While the Cyclone-class ships were intended to support special operations, they also can support the Coast Guard.
(U.S. Customs and Border Protection)
The Navy handed down the lead ship of the class, the former USS Cyclone (PC 1), to the Philippine Navy, where it’s still in active service. Five of these ships served with the Coast Guard for a few years before being returned to the Navy. These vessels are slated to be replaced by the Littoral Combat Ship in the near future.
Learn more about these small Navy vessels that prove that size doesn’t equal strength in the video below!
Planespotters found a Russian Mig-31 Foxhound taking off with a never-before-seen mystery weapon that could likely have an anti-satellite role, meaning it’s a nightmare for the US military.
The Foxhound is a 1980s Soviet fighter that remains one of the fastest and highest flying jets ever built. It’s ability to push Mach 3 near the edge of space with large weapons payloads makes it an ideal platform for firing anti-satellite missiles, which Russia appears to have tested in September 2018.
The War Zone noticed Russian aviation photographer ShipSash snapping photos of the Mig-31 armed with a massive missile taking off from the Russian aviation industry’s test center in Zhukovsky near Moscow on Sept. 14, 2018.
Pictures of the Mig-31 at Zhukovsky with the mystery missile can be seen here and here.
The Mig-31 has enjoyed somewhat of a rebirth in recent years as a platform for new Russian super weapons, like the Kinzhal hypersonic anti-surface missile that Russian President Vladimir Putin said could evade any US defenses.
The Mig-31 has a history of use in anti-satellite programs, but the new missile appears to show a renewed effort in that direction.
Two Russian MiG-31 Foxhounds with Kinzhal hypersonic missiles photographed over Moscow, May 5, 2018.
(Russian Defense Ministry)
The US, Russia, and China have all demonstrated anti-satellite capabilities in the past, and as war increasingly relies on information shared via satellite, attacking these critical nodes increasingly makes sense.
It’s unknown if the Mig-31 spotted in September 2018 carried an anti-satellite missile or some kind of satellite launcher, though they both serve a purpose in space-based warfare. Since both sides can destroy satellites, a space-based war would likely involve the downing of old satellites and launching of new satellites at a fast pace.
But that’s where space warfare meets its extreme environmental limit. Space debris orbiting the earth at many times the speed of sound could eventually threaten all existing satellites, plunging the earth back to a pre-Cold War state of relying entirely on terrestrial communications.
While many Russian and Chinese planes still have analog controls and gauges, the US relies most heavily on space assets and GPS, meaning space war would be more of a nightmare for Washington than Moscow.
This article originally appeared on Business Insider. Follow @BusinessInsider on Twitter.
Editor’s Note: This story has been updated to reflect that the event occurred on a test vessel, not aboard the Ford as previously stated.
The Navy recently got a step closer to getting the first ship in its new class of aircraft carriers ready for combat missions with a live-fire test off the coast of California.
A drone was taken out by Raytheon’s latest integrated combat system that’s being developed for the supercarrier Gerald R. Ford, Raytheon announced Feb. 5, 2019. The event took place on a test vessel off the coast of California, said Ian Davis, a Raytheon spokesman.
The system the Navy used to take down the drone is called the Ship Self-Defense System. It integrates a myriad of equipment that will be used aboard the Navy’s first Ford-class carrier, such as sensors, missiles and radars.
Raytheon program manager Mike Fabel said in a release that the new system allowed for “seamless integration” when its sensors and missiles were put to the test.
Aircraft carrier Gerald R. Ford.
(U.S. Navy photo by Chief Mass Communication Specialist Christopher Delano)
“This first-of-its-kind test [proves] the ability of the system to defend our sailors,” Fabel said. “This integrated combat system success brings Ford [herself] one step closer to operational testing and deployment.”
At least five of the integrated-combat system’s capabilities, which are also used on amphibious assault ships, were used during the live-fire event, according to the release detailing the test.
That included a radar that searched for, tracked and illuminated the target; the Ship Self-Defense System, which processed the data and passed launch commands to the missile; and missiles that took out the targeted drone.
The Ford, which is the first in its class of next-generation carriers, is expected to deploy in 2022.
The first in the new generation of carriers, the flattop has faced a series of mechanical and technological setbacks. That has left lawmakers and the commander in chief pressing Navy officials to explain the issues, including those with the Electromagnetic Aircraft Launch System and advanced weapons elevators.
Adding large numbers of new next-generation destroyers will substantially change the Navy’s ability to conduct major maritime warfare operations by enabling surface forces to detect enemy attacks at much farther distances, launch long-range strikes with greater precision and destructive force, and disperse offensive forces across much wider swaths of ocean.
The US Navy has awarded deals for 10 new high-tech DDG 51 Flight III Destroyers and built in options to add even more ships and increase the “build rates” for construction of new warships — all as part of a massive strategic push to accelerate fleet growth and usher in a new era of warfighting technology for the Navy.
Six of the new destroyers will be built by Huntington Ingalls Industries in a billion deal, and four of them were awarded to General Dynamics Bath Iron Works for .9 billion, according to a Navy announcement. The acquisition is a multi-year procurement intended to reach from this year through 2022.
“We also have options for an additional five DDG 51s to enable us to continue to accelerate delivery of the outstanding DDG 51 Flight III capabilities to our Naval force,” James F. Geurts, assistant secretary of the Navy for research, development and acquisition, said in a written Navy statement.
Meanwhile, the Navy has now started construction on its first new Flight III DDG 51 surface warfare destroyer armed with improved weapons, advanced sensors and new radar 35-times more sensitive than most current systems, service officials announced.
USS Cole and two other Arleigh Burke-class vessels docked at Naval Station Norfolk in July 2009.
Construction of the first DDG-51 Arleigh Burke-class Flight III Destroyer is part of a sweeping Navy and Pentagon effort to speed up delivery of new warships and expand the surface fleet to 355 ships on an accelerated timeframe.
Navy Flight III Destroyers have a host of defining new technologies not included in current ships such as more on-board power to accommodate laser weapons, new engines, improved electronics, fast-upgradeable software, and a much more powerful radar. The Flight III Destroyers will be able to see and destroy a much wider range of enemy targets at farther distances.
In fact, a new software and hardware enabled ship-based radar and fire control system, called Aegis Baseline 10, will drive a new technical ability for the ship to combine air-warfare and ballistic missile defense into a single system.
The AN/SPY-6 radar, also called Air and Missile Defense Radar, is engineered to simultaneously locate and discriminate multiple tracks.
This means that the ship can succeed in more quickly detecting both approaching enemy drones, helicopters and low flying aircraft as well as incoming ballistic missiles.
The Raytheon-built AN/SPY-6(V) radar is reported by developers to be 35-times more powerful than existing ship-based radar systems; the technology is widely regarded as being able to detect objects twice as far away at one-half the size of current tracking radar.
The farther away ship commanders can see approaching threats, across the spectrum of potential attack weapons, the faster they are able to make time-sensitive decisions about which elements of a ship’s layered defense systems should be used.
The AN/SPY-6 platform will enable next-generation Flight III DDG 51s to defend much larger areas compared with the AN/SPY-1D radar on existing destroyers. In total, the Navy plans as many as 22 Flight III DDG 51 destroyers, according to a previously completed Navy capabilities development document.
(U.S. Navy photo by Mass Communication Specialist Seaman Apprentice Joshua Adam Nuzzo)
The AN/SPY-6 is being engineered to be easily reparable with replaceable parts, fewer circuit boards and cheaper components than previous radars, according to Raytheon developers; the AMDR is also designed to rely heavily on software innovations, something which reduces the need for different spare parts, Navy program managers have announced.
Service officials say the new ship uses newly integrated hardware and software with common interfaces will enable continued modernization in future years. Called TI 16 (Technical Integration), the added components are engineered to give Aegis Baseline 10 additional flexibility should it integrate new systems such as emerging electronic warfare or laser weapons
In early 2018 the ship’s program manager Capt. Casey Moton said that special technological adaptations are being built into the new, larger radar system so that it can be sufficiently cooled and powered up with enough electricity. The AMDR will be run by 1000-volts of DC power.
The DDG Flight III’s will also be built with the same Rolls Royce power turbine engineered for the DDG 1000, yet designed with some special fuel-efficiency enhancements, according to Navy information.
The AMDR is equipped with specially configured cooling technology. The Navy has been developing a new 300-ton AC cooling plant slated to replace the existing 200-ton AC plant, Moton said.
Before becoming operational, the new cooling plant will need to have completed environmental testing which will assess how the unit is able to tolerate vibration, noise and shocks such as those generated by an underwater explosion, service officials said.
DDG 51 Flight III destroyers are expected to expand upon a promising new ship-based weapons system technology fire-control system, called Naval Integrated Fire Control – Counter Air, or NIFC-CA.
The technology, which has already been deployed, enables ship-based radar to connect with an airborne sensor platform to detect approaching enemy anti-ship cruise missiles from beyond the horizon and, if needed, launch an SM-6 missile to intercept and destroy the incoming threat, Navy officials said.
Navy developers say NIFC-CA presents the ability to extend the range of attack missiles and extend the reach of sensors by netting different sensors from different platforms — both sea-based and air-based together into one fire control system.
The system hinges ship-based Aegis Radar — designed to provide defense against long-range incoming ballistic missiles from space as well as nearer-in threats such as anti-ship cruise missiles.
Through the course of several interviews, SPY-6 radar developers with Raytheon have told Warrior Maven that simulate weapons engagements have enabled the new radar to close what’s called the “track loop” for anti-air warfare and ballistic missile defense simulations. The process involves data signal processing of raw radar data to close a track loop and pinpoint targets, Raytheon developers said.
The radar works by sending a series of electro-magnetic signals or “pings” which bounce off an object or threat and send back return-signal information identifying the shape, size, speed or distance of the object encountered.
The development of the radar system is hastened by the re-use of software technology from existing Navy dual-band and AN/TPY-2 radar programs, Raytheon developers added.
The guided-missile destroyer USS Arleigh Burke transits the Chesapeake Bay on its way back into port.
(U.S. Navy Photo by Mass Communication Specialist 1st Class RJ Stratchko)
AN/SPY-6 technology, which previously completed a Critical Design Review, is designed to be scalable, Raytheon experts say.
As a result, it is entirely plausible that AMDR or a comparable technology will be engineered onto amphibious assault ships, cruisers, carriers, and other platforms as well.
Raytheon statements say AN/SPY-6 is the first truly scalable radar, built with radar building blocks — Radar Modular Assemblies — that can be grouped to form any size radar aperture, either smaller or larger than currently fielded radars.
Raytheon data on the radar system also cites a chemical compound semi-conductor technology called Gallium Nitride which can amplify high-power signals at microwave frequencies; it enables better detection of objects at greater distances when compared with existing commonly used materials such as Gallium Arsenide, Raytheon officials explained.
Raytheon engineers tell Warrior that Gallium Nitride is designed to be extremely efficient and use a powerful aperture in a smaller size to fit on a DDG 51 destroyer with reduced weight and reduced power consumption. Gallium Nitride has a much higher break down voltage so it is capable of much higher power densities, Raytheon developers said.
This article originally appeared on Warrior Maven. Follow @warriormaven1 on Twitter.
The B-18 was a variant of the successful DC-2 airliner. As a bomber, it wasn’t bad, either: It could haul 4,400 pounds of bombs and had a maximum range of 1,200 miles. The plane had a six-man crew, a top speed of 223 miles per hour, and was equipped with three .30-caliber machine guns for defense.
The problem was that everyone knew that the B-18, which Douglas originally called the DB-1, won by default. The B-17 prototype had clearly out-performed the B-18 in the trials before the fateful crash — and the service test versions, called Y1B-17s, were even better than the crashed prototype. They could haul 8,000 pounds of bombs up to 3,320 miles at a top speed of 256 miles per hour. Despite the crash, it was emerging as the preferred choice.
The B-18 was indeed cheaper and the technology within was proven and safe. As a result, the Army Air Corps bought 217 B-18s. Some of these planes were sent to the Philippines and Hawaii to hold the line — until the B-17 was ready.
Three B-18s fly in formation near Hawaii prior to the attack on Pearl Harbor. On December 7, 1941, most were destroyed on the ground.
(Photo by Harold Wahlberg)
Despite winning the developmental competition, most officials didn’t believe in these planes by 1940. During the attack on Pearl Harbor, the majority of America’s B-18s were destroyed on the ground. The surviving airframes were then relegated to secondary roles. Over 120 B-18s were later modified to become maritime patrol planes — they defeated two German U-boats.
The B-18 did see most of its action in secondary roles.
The B-18s made its most significant contributions as a test platform. Some were modified to try a 75mm howitzer as an aircraft armament. Although the B-18 wasn’t a suitable platform for the huge gun, the data collected helped make the weapon practical for the B-25G and B-25H, improved versions of the bomber that would later carry out the Doolittle Raid.
The United States Air Force has a B-18 at its national museum.
All in all, the B-18 had a much less storied career than the B-17, but it still had an honorable service career during World War II.
To see the plane that once beat the B-17 in action, watch the video below!
Not many remember the Australians’ commitment to aiding the United States in Vietnam, but the Aussies were there, and they sent their best. Australia’s best troops included their very own Special Air Service, special operators in the mold of Britain’s SAS, formidable fighters capable of bringing the enemy’s method of irregular warfare right back home to Hanoi.
The Aussies weren’t content with the M-16, for a number of reasons, so they opted instead to do a little frontier mechanical work on their weapons. The end product became known as “The Bitch.”
When the M-16 first took over for the M-1 Garand as a standard-issue infantry weapon, the result was less than stellar. It jammed. A lot. Frustrated troops began leaving their M-16s at home and using AK-47s captured from the enemy instead. The Aussies preferred a weapon that worked. Even after the weapon was updated to fix its issues, the Australians still opted for a different solution. They liked how handy the M-16 could be, but they wanted the stopping power of a 7.62 round.
But the barrel of the S1A2 self-loading rifle was so heavy… what to do?
The Australian special operators lopped that heavy barrel and its tripod off at the end of the gas block. Then, the MacGuyvers from Down Under fashioned special flash suppressors for the new muzzle for those who wanted it. For those who didn’t, they just left the weapon without any kind of suppression at all. The new, shorter barrel was louder and produced a much bigger bang for the buck.
They wanted the Communists to know who was pulling the triggers and raining death on their Ho Chi Minh Trail parade. If that weren’t enough, sometimes the operators would put a pistol grip on the end so they could control the weapons in fully automatic settings. Others preferred a grenade launcher attachment.
Fun was had by all.
Feature image: Public domain via Wikimedia Commons
Air Force Airman 1st Class Nathan Kosters, the youngest F-35 crew chief in the 34th Aircraft Maintenance Unit, was born in 1996. “The Macarena” somehow was No. 1 on the charts, “Independence Day” topped the box office, and the F-16 Fighting Falcon had already been flying for 22 years.
The 20-year-old native of Byron Center, Michigan, and his fellow F-35A Lightning II maintainers generated combat sorties with America’s youngest jet at Red Flag.
The Jan. 23-to-Feb. 10 iteration of Air Force’s premier air combat exercise included both U.S. and allied nations’ combat air forces, providing aircrews the experience of multiple, intensive air combat sorties in the safety of a training environment.
“It’s pretty amazing. It’s like a family atmosphere,” Kosters said. “We’re extremely busy, working long hours, but everyone pulls together and makes sure the mission is successful.”
Inspired by His Father
Growing up, he learned hard work from his father, a carpenter. He learned how to get up early and work until the job was done. The two worked side by side, he said, even throughout his father’s cancer treatments. “He is an inspiration to me — never giving up,” Kosters said. “Working was a great opportunity to be close to him.”
Kosters joined the Air Force a little over a year ago after graduating from high school and working in construction for awhile, because he wanted to leave the Midwest, get an education and see the world, he said. He got high scores on his entrance test, and the F-35 maintenance world, hungry for new talent, put him in the pipeline.
“I didn’t really know anything about the F-35,” Kosters said. “I knew it was the newest jet, and I heard all the negative press about it. My dad and I started reading up on it. He probably knew more about it than I did.”
After technical training and hands-on experience, Kosters said, he is happy he is where he is.
“It’s cool, working with the latest technology, he added. “I don’t want to make it sound like maintenance is easy. It’s just advanced. It’s great to be able to plug in a laptop and talk to the aircraft.”
Based at Hill Air Force Base, Utah, the 34th Fighter Squadron and Aircraft Maintenance Unit are the first combat-coded F-35A units in the Air Force. They were created by bringing together a team of experienced pilots and maintainers from across the Air Force’s F-35 test and training units. Kosters was one of the first pipeline maintainers to join the 34th AMU straight from basic training and tech school, and Red Flag is valuable experience for that greener group.
“At home, our young maintenance airmen are practicing and learning every day. Here, we’re able to put that training into a realistic scenario and watch them succeed and learn how to overcome challenges,” said Air Force Senior Master Sgt. Robert Soto, lead production superintendent for the 34th AMU.
“It’s not glorious,” Kosters said. “You’re not working 9 to 5. Your uniform is not going to stay nice and clean. But, next to being a pilot, I feel like I have the best job there is. It’s gratifying to see those jets take off.”
Kosters said he and his fellow maintainers take pride as they hear from pilots how their aircraft are performing in the fight.
“It’s had its doubters in the world, but it’s nice to prove people wrong with all eyes on us, especially here,” Kosters said. “The first couple missions, it was the F-35 versus everyone else, and our guys were showing them that the F-35 is a superior plane. We’re like varsity.”
Sikorsky’s SB-1 Defiant, an aircraft that uses a modified helicopter design to achieve great speed and fuel-efficiency as well as maneuverability, took its first flight on March 21, 2019, exciting military aviation fans who hope that it’s selected for the Army’s Future Vertical Lift Program.
Sikorsky-Boeing #SB1 Defiant Completes First Flight
The SB-1 Defiant is one of two top contenders for the Future Vertical Lift program, the Army’s effort to replace its aging helicopter fleet. The Army will select a new utility helicopter, likely either the SB-1 Defiant or the V-280 Valor from Bell, that will ferry troops and lighter loads, carry out the wounded in MEDEVAC missions, and fill the rest of the roles currently carried out by the UH-60 Black Hawk.
The current aviation debate is interesting for military aviation aficionados for a few reasons. One is that this sort of contest only occurs every few decades. Another is that neither of the top contenders for the program is a conventional helicopter. The SB-1 Defiant is an evolution of Sikorsky’s X-2 demonstrator. It has two rotor blades similar to a conventional helicopter, but it’s pushed forward by a rear propeller and has no conventional rear rotor.
This makes it much more efficient and faster than a conventional helicopter while retaining all the versatility and maneuverability.
The Sikorsky SB-1 Defiant takes its first flight. It’s a strong contender for the Army’s Future Vertical Lift program.
Its primary contender, meanwhile, is of a tiltrotor design. It can fly fast and far, even farther than the Defiant, but is not as maneuverable or able to fit in as small of places and landing zones. It’s also a direct successor to the controversial V-22 Osprey, a plane that had a horrible safety record during testing. The V-22 did do well with the Marine Corps in the field for a few years, but has run into trouble again recently, suffering four catastrophic crashes from 2015 to 2017.
So, yeah, soldiers care who wins because it decides what will carry them into battle in the 2030s, 2040s, and beyond. And whatever aircraft the Army chooses will instantly have thousands of orders, allowing it to be produced at scale, meaning the manufacturer can offer additional copies to the other services for cheap.
So, the Army’s choice will impact what aircraft the Navy, Air Force, and Marine Corps can afford to buy for their own services, heavily pushing them to use the same aircraft in at least some roles. (The U.S. Navy, Air Force, Coast Guard, and Marine Corps all bought UH-60 variants after the Army did, though the Marine Corps bought very few and placed them only in specialty roles.)
With all this competition and the long-term impact of the decision, it was a mark in the V-280 Valor’s favor that its aircraft had been flying since December 2017 while the SB-1 Defiant was still limited to ground tests until the March 21 test. Now that both aircraft have flown without shaking themselves apart, the manufacturers will have to prove whether each aircraft can live up to the hype.
And then the Army will begin to make its choice, setting the tone of military aviation for the next few decades.
Australian airline Qantas is taking the next steps towards its goal of having nonstop 19-hour flights between Sydney and London and New York.
The airline has openly discussed the endevour — internally known as “Project Sunrise” — for several years, following the successful launch of a slightly shorter, but still lengthy, nonstop flight between Perth and London in March 2018.
That route is measured as about 9,000 miles and takes around 17 hours, while the Sydney-New York route would be around 10,000 miles, and the Sydney-London flight is about 500 miles longer.
Qantas is scheduled to receive three new Boeing 787-9 Dreamliner aircraft this fall — one each in October, November, and December 2019. The planes are being built at Boeing’s Seattle plant, and would normally be flown by Qantas pilots straight to Australia from there.
(Photo by Suhyeon Choi)
Instead, the airline plans to fly the planes to New York and London first, and then fly nonstop to Sydney from there.
The planes won’t have paying customers — instead, they’ll each have about 40 people on board — including crew — most of whom will be Qantas employees. the airline says it plans to study how those on board react to the lengthy 19-hour flights.
According to the airline, “[s]cientists and medical experts from the Charles Perkins Centre will monitor sleep patterns, food and beverage consumption, lighting, physical movement, and inflight entertainment to assess impact on health, wellbeing and body clock.”
Commercial flights with full or mostly-full passenger loads are not currently possible due to the range of the airplanes available today. Keeping the planes mostly empty will increase their range, making the test flights possible. A normal Qantas 787-9 can seat up to 236 passengers, plus crew, and carry both luggage and cargo, while still achieving a range of about 9,000 miles — the length of the Perth-London flight.
(Photo by John Kappa)
The airline is considering new ultra-long-range aircraft from Boeing and Airbus for the eventual New York and London to Sydney flights — Airbus’ rumored A350-1000ULR airplane, and Boeing 777X project, both of which are still being tested. Qantas has previously said it would make a decision around the end of 2019.
The world’s current longest flight— from Singapore to New York’s Newark Airport — is operated by a Singapore Airlines A350-900ULR configured with only business class and premium economy seats— no regular economy cabin.
This article originally appeared on Business Insider. Follow @BusinessInsider on Twitter.
One of the most magical feelings in the military is that moment you finally get back to the tent or barracks and can finally shed your Kevlar helmet and IOTV. That moment, when you can finally breathe and realize just how sweaty you were, is just plain glorious.
As much of a slight pain in the ass (figuratively speaking, of course. Literally, it’s a pain in the lower back and knees) as today’s armor is, it’s come a long way. Take, for instance, the first effective ballistic armor developed by the United States Army for WWI.
I present you to the unsightly behemoth known as the “Brewster Body Shield.”
When America made its entry into the first World War, it was an eye opener. War had changed drastically in only a few short years. Now, cavalry on horseback were useless against a machine gun nest, poison gas was filling the trenches, and fixed-wing, motor-driven airplanes were being used for war just twelve years after the Wright Brothers made their historic flight at Kitty Hawk.
The Italians had started fielding their own updated version of knights’ armor for use by the Arditi, but it had more of a symbolic meaning than any practical use. The Germans began giving their sappers protective armor that could take a few bullets along with protecting its wearer’s vital organs from the shock of explosives. America thought they could outdo them all with their own, suped-up version.
America wanted some sort of protection for its infantrymen if they ever dared to cross the barrage of bullets that flew across No-Man’s Land and they needed it as fast as they could. The U.S. Government turned to a man who created armor intended for boxing training, Dr. Guy Otis Brewster.
Dr. Brewster began creating a suit of armor that was made out of 0.21 inch chrome nickle steel — enough to withstand .303 British bullets at 2,700 ft/s (820 m/s). It was also given a V-shaped design to minimize the direct impact of any oncoming bullets. The whole thing came in two pieces and weighed a total of 110 lbs.
Then came time for the field test. Dr. Brewster invited Army officers and representatives from the steel mills and rubber companies to come witness. Being the insane scientist that he was, he donned the armor himself and stood in the firing line for the test.
His assistant swung at him with a hammer and a sledgehammer before eventually moving on to being shot by a Springfield rifle. He said that being shot it the suit was “only about one-tenth the shock as being struck by a sledgehammer.”
You can watch the recording below.
Despite its protective capabilities, it was deemed too heavy, too clumsy, and way too large to ever be fielded. Dr. Brewster didn’t take that news lightly and wanted to prove its worth. He tested it again and was reportedly able to withstand a hail of bullets from a Lewis Machine Gun — with him inside the suit, obviously.
In the end, he never managed to get the Body Shield approved by the U.S. government — seeing as it was impossibly immobile and occluded visibility almost entirely. He would, however, later make a steel-scaled waistcoat that resembles more modern flak vests.
On July 1, 2019, Boeing announced that T-X aircraft N381TX flew the first official Engineering and Manufacturing Development (EMD) flight test from Boeing’s St Louis plant in Missouri. Boeing did not disclose further details about this flight although the Chief T-X Test Pilot, Steve ‘Bull’ Schmidt, said: “She flew just superb. First EMD test points went off without a hitch”.
The aircraft is one of the two company-funded prototypes built for the Air Force T-X Advanced Pilot Training program and modified into the EMD design after the first flight test campaign. The two aircraft performed 72 test flights between December 2016 and December 2018, gathering data ahead of the EMD testing. During the last months, Boeing and Saab (rear fuselage supplier for T-X) modified the prototypes with ACES 5 ejection seat, an updated On-Board Oxygen Generation System (OBOGS) and other minor changes. Boeing is counting on completing the critical design review of the final EMD configuration by the end of 2019.
The two T-X prototypes in formation during a flight test.
The U.S. Air Force awarded the $ 9.2 billion T-X contract to Boeing and Saab in September 2018 for 350 trainer aircraft, 46 ground-based training systems and related ground equipment, with other 125 aircraft on option.
The first five aircraft and seven simulators will be delivered to Joint Base San Antonio-Randolph (Texas) in 2023, with Initial Operational Capability (IOC) planned by the end of 2024 and Full Operational Capability (FOC) planned by 2034. The T-X trainer is due to replace the Northrop T-38 Talon, the world’s first supersonic and most produced jet trainer, that has been in service for over 50 years.
The new aircraft is powered by a single General Electric Aviation F404 engine (the same engine used by the Saab Gripen C/D and legacy F/A-18) and has a design similar to the F/A-18, with leading-edge root extensions (LERX) and twin tails that can provide high performance training for pilots that will fly US front-line fighters. The cockpit features a touchscreen large-area display (LAD), digital Up-Front Controller (UFC) and standby instruments, Hands On Throttle And Stick (HOTAS) controls and a low profile Head-Up Display (HUD), much like the F-35 cockpit or the proposed cockpits for Boeing’s F/A-18E/F Block III and F-15X and Saab’s Gripen E.
This article originally appeared on The Aviationist. Follow @theaviationist on Twitter.
Hundreds of Marines will join their British counterparts at a massive urban training center this summer that will test the leathernecks’ ability to fight a tech-savvy enemy in a crowded city filled with innocent civilians.
The North Carolina-based Kilo Company, 3rd Battalion, 8th Marines, will test drones, robots and other high-tech equipment at Muscatatuck Urban Training Center near Butlerville, Indiana, in August 2019.
They’ll spend weeks weaving through underground tunnels and simulating fires in a mock packed downtown city center. They’ll also face off against their peers, who will be equipped with off-the-shelf drones and other gadgets the enemy is now easily able to bring to the fight.
It’s the start of a four-year effort, known as Project Metropolis, that leaders say will transform the way Marines train for urban battles. The effort is being led by the Marine Corps Warfighting Laboratory, based in Quantico, Virginia. It comes after service leaders identified a troubling problem following nearly two decades of war in the Middle East: adversaries have been studying their tactics and weaknesses, and now they know how to exploit them.
Sgt. Dalyss Reed, a rifleman with Kilo Company, Battalion Landing Team 3rd Battalion, 5th Marine Regiment, 11th Marine Expeditionary Unit, maneuvers through a breach hole while conducting an urban platoon assault.
(Photo by Lance Cpl. Dalton S. Swanbeck)
With tensions heating up with Iran, China and Russia, it’s likely Marines could face a far more sophisticated enemy than the insurgent groups they fought in Iraq and Afghanistan.
Just this week, Iran shot down a massive U.S. Navy drone capable of flying at high altitudes that collects loads of surveillance data. President Donald Trump said he called off retaliatory strikes just minutes before the operations were slated to kick off.
Less than two weeks prior, a Russian destroyer nearly collided with a U.S. Navy warship in the Philippine Sea. These are just some of the examples of close calls that could have left Marines and other U.S. troops facing off against near-peer militaries equipped with high-tech equipment in highly populated areas.
At the same time, the Marine Corps’ Operating Concept, a document published in 2016, found the service isn’t manned, trained or equipped to fight in urban centers, Maj. Edward Leslie, lead planner for Dense Urban Operations at the Warfighting Lab, told Military.com.
“The enemy has changed,” Leslie said. “… They obviously have more access to drones. I think the enemy’s sensing capabilities have increased, they have the ability to see in the night just as well as we can, and they have capabilities that can exploit our technology or disrupt our technology.”
(U.S. Marine Corps Photo)
The Marine Corps isn’t alone in grappling with these new challenges. The Army is spending half a billion dollars to train soldiers to fight underground, and has begun sending small-units to its massive training center in California where leaders are challenged with more complex warfighting scenarios.
The Army also found that young sergeants in most infantry and close combat units don’t know how to maneuver their squads or do basic land navigation, Military.com reported this spring.
Those are skills Marines must continue to hone, Leslie said, since so many advantages they’re used to having on the battlefield are leveling off. It’s not just room-clearing Marines need to be good at, he said, but overall urban operations — things like figuring out ways to penetrate a building without destroying it since it’s right next to a school or hospital.
“I think that’s the value we’re going to get [with Project Metropolis],” he said.
A next-gen fight
The training center Marines and British Royal Marines will use this summer is a sprawling 1,000-acre site that houses dozens of buildings, some with up to seven stories and basements. The complex also has more than a mile’s worth of underground tunnels and active farmland.
The urban center has been used not just to train troops, but to help government leaders prepare for pandemic responses or natural disasters as well.
Kilo Company will complete four phases during the month they spend there, Brig. Gen. Christian Wortman, who recently served as the Warfighting Lab’s commanding general, told reporters May 2019. It will culminate with a five-day force-on-force simulated battle in which the Kilo Company Marines, equipped with new high-tech gear, face off against a like-minded enemy force with its own sophisticated equipment.
The concept was introduced by Commandant Gen. Robert Neller last summer to help Marines better prepare to fight a near-peer enemy. The British Royal Marines participating in the exercise will either join Kilo Company’s efforts against the aggressor, or act as another force operating in the same region, Leslie said.
Project Metropolis will build on years of experimentation the Marine Corps has conducted as part of its Sea Dragon 2025 concept. Leslie said the grunts picking up the next leg of experimentation in Indiana will be further challenged to use some of the new technology Marines have been testing in a more complex urban setting, similar to what they’re likely to face in a future warzone.
Marines have been experimenting with different infantry squad sizes to incorporate drone operators. Now, Leslie said, they’ll look at how to organize teams operating a new tactical self-driving vehicle called the Expeditionary Monitor Autonomous Vehicle, which will carry a .50-caliber machine gun.
“That’s going to be a major thing,” he said. “We’re looking to see, what’s the table of organization look like to work with that, and is it any different if it’s an urban vehicle?”
Marines practice Military Operations on Urban Terrain at Camp Buehring, Kuwait, Nov. 23, 2012. The Scout Sniper Platoon, Weapons Company, Battalion Landing Team 3/5, 15th Marine Expeditionary Unit is deployed as part of the Peleliu Amphibious Ready Group as a U.S. Central Command theater reserve force, providing support for maritime security operations and theater security cooperation efforts in the U.S. 5th Fleet area of responsibility.
(U.S. Marine Corps photo by Cpl. Timothy R. Childers)
Rifle squads will continue experimenting with unmanned aerial systems, Leslie added, to spot enemy positions without sending someone into a danger zone. They’ll use ground robots that have the ability to map the insides of buildings, and will test Marines’ decision-making when they’re overwhelmed with information.
“Really want we want to see is how the tech integrates and also how it operates in a dense urban environment,” he said.
Kilo Company will also work with nonlethal systems, Wortman said, which they can turn to if they’re in an area where there could be civilian casualties. They’ll have access to kamikaze drones and “more sophisticated tools for delivering lethal fires,” he added.
It’s vital that they see that Marines are able to put these new tools to use quickly and easily, Wortman said, as they don’t want them to be fumbling with new systems in the middle of combat situations.
Building on the past
Marines aren’t new to urban fights.
Leathernecks saw some of the bloodiest urban battles since Vietnam’s Battle of Hue City in Fallujah, Iraq. About 12,000 U.S. troops fought in the second leg of the 2004 battle to turn that city back over to the Iraqi government. In the fierce battle, which involved going house-to-house in search of insurgents, 82 U.S. troops were killed and about another 600 hurt.
The Marines learned during those battles, Leslie said. But a lot has changed in the last 15 years, he added. With adversaries having access to cheap surveillance drones, night vision and other technology, military leaders making life-and-death decisions on the battlefield must adjust.
The goal, Wortman said, is to keep Marines armed with and proficient in to keep their edge on the battlefield.
Every city has a different character, too, Leslie added, so what Marines saw in Fallujah is not going to be the same as what they can expect in a new fight.
There has also been a great deal of turnover in the Marine Corps since combat operations slowed in Iraq and Afghanistan, Leslie said. Today’s generation of Marines is also incredibly tech-savvy, Wortman said, and they’re likely to find ways to use some of the new gear they’re handing to them during this experiment and come up with innovative new ways to employ it.
“We have the expectation that these sailors and Marines are going to teach us about the possibilities with this technology because they’ll apply it in creative … ways the tech developers didn’t fully anticipate.”
This article originally appeared on Military.com. Follow @militarydotcom on Twitter.
In 2009, the Department of Defense acquisition chief John J. Young, Jr. issued a mandate requiring the military departments to find new ways to reduce their use of hexavalent chromium (also known as hex-chrome or Cr6+). Hex chrome, which became infamous in the eyes of the public after the release of the film, Erin Brockovich, is a carcinogen that is harmful to humans and the environment. DoD maintenance facilities go to painstaking lengths to reduce the level of exposure sustained by their maintenance technicians due to hex chrome.
Hex chrome offers important corrosion prevention and control qualities in organic pre-treatments and primers used to coat a variety of military aircraft. For example, most coatings and primers used on legacy fighter and cargo aircraft such as the Navy’s F/A-18 and F-14, the Air Force’s C-130, C-5, and F-16 contain hex chrome, and the Army’s H-60 Black Hawk helicopter.
Chromate-based corrosion inhibitors are widely recognized as the best inhibitors available to the DoD. Their high level of performance means that they are still used prolifically as a coating for all types of military aircraft.
(U.S. Air Force photo by Airman 1st Class Joshua Kleinholz)
The Delicate Balance of Finding Alternatives to Hex Chrome
Complicating the issue of finding alternatives to hex chrome is the drastic cost of corrosion faced by the U.S. military. According to a study released by the DoD Corrosion Policy and Oversight Office, the DoD spent nearly $20 billion on corrective corrosion actions in fiscal year 2016. That expenditure amounts to nearly 20 percent of the entire DoD maintenance budget.
Moreover, corrosion experienced by Navy and Marine Corps aircraft costs approximately $3.43 billion annually and accounts for almost 28 percent of all maintenance costs. Corrosion-related maintenance prevents active aircraft from being ready for mission tasking for approximately 57 days each year.
The high cost of corrosion within the DoD persists despite its prolific use of carcinogenic, but best-in-class, chromate primers.
Navy experts who attack the problem of chromates walk a delicate line between finding an environmentally benign inhibitor and refusing to sacrifice so much performance that the DoD maintenance budget swells even further. Since 2009, the search by DoD and industry for a non-chromate primer has persisted alongside the expectation of finding an alternative that performs just as well as current chromate-based primers. Among DoD officials and engineers, this expectation has become known as the “as good as” requirement.
In response to Young’s 2009 mandate, experts at the Materials Engineering Division of the Naval Air Warfare Command – Aircraft Division (NAWCAD) in Patuxent River, MD, re-energized their internal primer research and development efforts in an effort to push the performance of non-chromated primers closer to that of chromated primers, since the products qualified at the time were the best available, but still not good enough for many naval aviation applications
(U.S. Army photo)
To address this shortcoming, NAWCAD materials engineer Craig Matzdorf and chemical engineer William Nickerson, now with the Office of Naval Research, have invented their own solution to the problem. Their patented Active Aluminum-Rich (“Al-Rich”) technology is a powerful anti-corrosion chemical composition created for use in coating systems. The Al-Rich primer is a metalized, sacrificial, chromate-free, high-performance, anti-corrosion primer for use in all situations where a chromated primer is currently used.
“Al-Rich is superior to existing coatings based on the novel aluminum pigment that actively overcomes corrosion by electrochemical means,” said Matzdorf. “Current coatings rely on chemical inhibitors like chromate, which are less effective at fighting galvanic corrosion. We anticipate that the Al-Rich primer will reduce galvanic and other types of corrosion and its effect on the Navy’s cost and availability.”
Key Technology Components in Al-Rich Primer
Although metal-rich primers have existed for quite some time, there were some underlying problems. First, the most traditional metal-rich coatings, such as zinc-rich coatings, are far too heavy for aviation applications and are not effective on aluminum. Second, other metal-rich coatings did not have the longevity of performance in harsh operating environments. “The Al-Rich primer employs two unique approaches to alleviate these key issues and to provide corrosion protection at the level of chromate primers,” according to Matzdorf.
The first key component of the technology is the use of a specialty aluminum alloy as the pigment inside the primer. The alloy composition of this pigment is specifically chosen for its high efficiency. In turn, this high efficiency, in combination with the low density of aluminum, allows the coating to be applied at normal aviation thicknesses, thus eliminating weight concerns.
The technology’s second key component is a proprietary surface treatment applied to the pigment. By subjecting the primer’s pigment to a surface treatment, both the pigment’s overall level of performance and the primer’s overall length of performance are increased. A surface-treated particle boosts the performance of this metal-rich primer to meet the “as good as” requirement.
According to Matzdorf, these two key technology components combine to create a truly novel approach to non-chromated and high-performance primers. One area of Al-Rich primer’s performance excellence is its ability to reduce fastener-induced corrosion. Each time a titanium or stainless steel fastener is punched into the aluminum body of an aircraft, a potent corrosion cell is created. These corrosion cells cause prolific and expensive corrosion damage. For reasons that are likely to stem from its ability to protect aluminum electrochemically, the Al-Rich primer excels at preventing fastener-induced corrosion as well as filiform corrosion. In many scenarios, the Al-Rich primer outperforms its chromated counterparts at preventing these rampant corrosion problems.
Applications and Future Testing
Thus far, the Al-Rich primer has been applied to an Army H-60 helicopter, a NASA C-130 cargo plane, two Coast Guard H-60 tail sections, and various pieces of Navy support equipment. Engineers at NAWCAD have extensive lab data on this product and are now looking to test it extensively on a variety of DoD applications. However, to do so, the Navy needs to procure large batch sizes of the new primer. Because the Navy is not in the business of manufacturing commercial quantities of chemicals, it has begun licensing this Al-Rich primer technology to equipped and capable businesses.
Through funding sponsored by the Office of Naval Research over the next few years, the Navy plans to apply the new Al-Rich primer to larger and larger portions of its assets. Successful field demonstrations will allow the Navy to comply with the DoD mandate regarding hex chrome. According to officials at NAWCAD and the DoD Corrosion Policy and Oversight Office, Al-Rich primers represent an exciting new entry into the non-chromated anti-corrosion primer market.
